Pomona 4897-2 Banana Plug, Solderless & Stackable, 15 A, Red, 4897 Series
Our Part #35330.1
Condition:New
Mfr Part #4897-2
Pomona
Pomona 4897-2 Banana Plug, Solderless & Stackable, 15 A, Red, 4897 Series
Our Part #35330.1
Condition:New
Mfr Part #4897-2
$EACH
- Description
- Specifications
- Documents
- Designed to fit on the end of any 22 AWG to 18 AWG wire.
- Cross hole wire entry fits wires up to .12” (3mm) diameter.
- Available with tarnish resistant nickel or gold plating for very low contact resistance.
- Set screw simplifies assembly of test leads and jumpers by using a flat blade screwdriver.
- Fits standard panel and binding post banana jacks .161” to .166” (4,0mm to 4,2mm) diameter
Brand: Pomona
Series: 4897 Series
Voltage: 5000 V
Color: Red
Current: 15 A
Finish: Gold Plated
Insulation: Polypropylene
Material: Zinc Die Cast
Maximum Temperature: 122°F
Termination Type: Solderless and Stackable
Wire Size AWG: 18-22 AWG
