• Available in Metric and Inch/Metric models
• Available with SPC output capabilities
• Fast measurement frequency allows users to increase the number of readings per second, from 10 to 50, allowing for higher accuracy measurements of TIR and MAX/MIN
• Improved parameter setting software
• Analog bar provides easy-to-read values when scanning for Max, Min and TIR values
• Go/No-Go judgements are performed by setting the upper and lower tolerances
• Up to three sets of master values and upper/lower tolerance values can be memorized
• ABSOLUTE (ABS) linear scale eliminates the need for setting the origin point every time the micrometer is powered on
• Origin reset is not required even when data is re-displayed after disappearance due to insufficient illumination during use
• SPC output function allows for quick and easy data management in real time
• Functions include Key lock, parameter lock, PC-USB input, analog bar, fast measuring frequency, peak detection, calculation, counting direction switching, power On/Off, data output and inch/mm conversion (on inch/metric models only)
• Alarm: Low voltage, counting value composition error, over-flow error and tolerance limit setting error
• Unlimited response speed eliminates over-speed errors
• IP42 for protection against objects greater than 1mm and water
• Supplied in a fitted plastic case

The Mitutoyo ABSOLUTE Digimatic ID-C bore gage indicators are designed for dedicated inside measurements with minimum value hold and tolerance judgement function. Measurements are shown on a large, easy-to-read LCD display.

The Mitutoyo ABS digital ID-C digital indicators are specially designed for bore gage applications which are dedicated to providing highly accurate inside measurements up to 12.7mm/.5" in depth. Five buttons and status icons provide simple operation of many functions including measurement data memory to store up to nine measurement results. A Key Lock and Parameter Lock feature prevents accidental changing of settings during operation.
